API 5 CT Float Collar 5.5 in Carbon Steel for Well Drilling

Nama Merek:	SWS
MOQ:	1

Informasi Rinci

Deskripsi Produk

Informasi Rinci

Tempat asal:

Cina

Berat:

5 kg

Komponen inti:

Baja karbon

Tipe katup:

Katup tunggal & katup ganda

Jenis mesin:

Alat pengeboran

Jenis pemrosesan:

Penempaan

Jenis:

300 325 343

Ukuran:

Ukuran standar

Ukuran kerah mengapung:

5 1/2 ", 7", 9 5/8 ", 13 3/8"

Bore od:

6 ", 7 5/8", 10 5/8 ", 14 3/8"

ID Bore:

4 3/4 ", 6 1/4", 8 5/8 ", 12 3/8"

Min bore:

2 ", 2 3/8"

Jenis Thread:

5 1/2 "LCSG, 7" LCSG, 9 5/8 "LCSG, 13 3/8" LCSG

Peringkat tekanan:

4351, 3626 lb/in2

Ukuran sepatu mengambang:

5 1/2 ", 7", 9 5/8 ", 13 3/8"

Warna:

Permintaan klien

Menyoroti:

API 5 CT float collar

5.5 inch carbon steel float collar

well drilling float equipment

Deskripsi Produk

Auto-Filled Stab-in Float Collar With API and ISO Product Description Float equipment serves as the backbone of casing equipment used during primary cementing operations. Float equipment guides the casing to total depth and prevents contaminated mud from entering the casing. Also, it provides a landing point for casing wiper plugs, reinforces the lower end of the casing string, and ensures great accuracy of cement slurry displacement. Specification Name Size(in) Bore O.D.(in)
